Diode Laser + ipl +nd Yag Laser Machine
Technology: Diode laser+IPL+ND YAG laser
Function: Hair Removal, skin Rejuvenation, tattoo removal
Treatment area: Body Legs Arms
Diode laser wavelength: 755nm 808nm 1064nm
IPL wavelength: 480/530/590/640/690-1200nm
ND YAG wavelength: 532/1064/1320nm
Certification: CE， FDA，ISO13485
Warranty: 1 year
Description
Technical Parameters
Product introduction
The diode laser IPL Nd YAG laser machine is a high-tech beauty device that integrates multiple laser technologies and is widely used in beauty and medical scenarios such as hair removal, skin rejuvenation, and pigmentation treatment. The device uses high-performance diode laser (wavelength 808nm), intense pulsed light (IPL) and Nd:YAG laser (wavelength 1064nm and 532nm) technology. Based on selective photothermal effect, the laser energy accurately penetrates the skin to a specific depth, targeting hair follicles or pigment particles, and achieves the treatment goal through thermal destruction.
Product features
Multi-wavelength
Diode laser IPL Nd laser machine has multiple wavelengths. The 808nm wavelength of the diode laser is suitable for hair removal. The band of IPL (intense pulsed light) covers 500-1200nm, which can be used for skin rejuvenation and pigmentation treatment, while the Nd laser provides 532nm and 1064nm wavelengths, which can effectively treat superficial and deep pigment lesions. The characteristics of this multi-wavelength configuration are derived from the principle of selectivity of tissue absorption by different light waves, that is, lasers of different wavelengths have specific tissue absorption peaks. For example, the 808nm wavelength is mainly absorbed by melanin in hair follicles, the 532nm wavelength is sensitive to hemoglobin, and the 1064nm wavelength can penetrate deeper skin tissues to target deep pigments or vascular lesions. This selective photothermal absorption mechanism can effectively avoid thermal damage to non-target tissues, achieve efficient, safe and precise treatment effects, and meet diverse beauty needs.
Contact Cooling
The device uses sapphire for contact cooling. By installing a high thermal conductivity sapphire crystal on the laser emitter head, the sapphire crystal is directly in contact with the skin surface. Sapphire has excellent thermal conductivity (thermal conductivity is about 25 W/m·K, about 30 times higher than ordinary glass), which can quickly absorb and conduct heat from the skin surface, reducing thermal damage and pain during treatment.
Long-life Laser Light Source
The equipment uses high-quality diode chips and Nd laser rods. The life of the diode laser light source can reach more than 2,000 hours, and the Nd laser rod has undergone a strict high-temperature sintering process and multi-layer coating treatment, and its service life can reach more than 3,000 hours. This ensures the durability of the equipment, reduces the maintenance frequency, and effectively reduces operating costs, which is especially suitable for medical beauty institutions with high frequency use.
